Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 90
SINGLE UNIT 8ATTERYSHORT SERVICE … Figs. 3,934 to 3,937.— Hydraulic analogy of parallel connection.Figs. 3,934 and 3,936 show conditions of a single tank, andthree tanks in parallel, furnishing equal flows. It is apparentthat in the case of the parallel tanks, each is furnishing onlyone-third the total flow, while the single tank…
Electrical engineering
