to work,and the remainder, neglecting radiation, etc., is rejected to therefrigerator. 87. Simple Thermodynamic Engine. Before making a generaldemonstration it will be instructive to give, as an illustration, asimple concrete, though by no means economical, method for theconversion of heat into… … Fig. 9. the rod rests against the support SSf, and the other end againstone of the teeth of the disk, supported on an axis through 0. Apawl P, pivoted on the support SS, also engages one of the teethof the disk. Connected to this disk is a drum, having wound overit a cord, supporting a resistance…
