High frequency apparatus, design, construction and practical application; a practical treatise for electrical engineers, electricans, physicians, students and experimenters (1920)
Curtis, Thomas Stanley · New York, Norman W. Henley publishing company · leaf 112
Fig. 50.—Transformer in its case Tesla. The description herewith will accordingly be de-voted to a discussion of the latter type only. With reference to Fig. 51, the base, 1, is of suitable drywood as is also the upright support, 2. The dimensions ONE-HALF KILOWATT TRANSFFORMER OUTFIT 107 … Fig. 51.—Oscillation transformer composed of two Oudin resonators placed tase to base 108 HIGH FREQUENCY APPARATUS
Electric apparatus and appliances
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
