Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 33

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 33
es the rest. Sec-tion 31 explains the whole thingfor a belt requiring but onemovement. Machines having a backingbelt are provided for by the ar-rangement shown in section 32,in which the piston and beltshifter are held in a centralposition by two coiled springswhen the belts are on the… … TRANSMISSION OF POWER. 31

Mechanical movements
