Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 187
the current to burst through the air gap and pro-duce a spark, hence the term high tension ignition. Sincethe spark jumps from one electrode to the other, this method 160 A UDELS ANSWERS of igniting the charge is also known as the jump spark system.The spark itself is properly described by the… … ,jw\aaaaW |~^c Fig. 71.—Circuit diagram of the Eisemann magneto. A, armature; C,interrupter; Cl, C2, C3, C4, high tension leads to cyUnders; D, high tensiondistributer disc; Dl, D2, D3, D4, distributer wipe contacts; G, secondaryground on metal of engine; K, condenser; M, permanent magnets; N,…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
