The history and rudiments of architecture; embracing, I. The orders of architecture; II. Architectural styles of various countries; III. The nature and principles of design in architecture; and, IV. An accurate and complete glossary of architectural terms .. (1853)

Bullock, John, ed · New York, Stringer & Townsend · leaf 272

An illustration from The history and rudiments of architecture; embracing, I. The orders of architecture; II. Architectural styles of various countries; III. The nature and principles of design in architecture; and, IV. An accurate and complete glossary of architectural terms .., 1853, leaf 272
of the soffit or underside of the abacus which overhang the echinuse e e e ; and s s the soffit of the architrave. From this, the rela-tion between the abacus and architrave, and how much the formerexceeds or projects out beyond the latter, will be better understoodthan by the engraving Fig. 1 in…

Architecture · Architecture -- History
