c- Q 0 L<y tricity is generatedat the generator (6)at 11,000 volts, andis sent out to thesub-stations (S) inconduits underground. Here itruns through trans-formers and isstepped down to2300 volts. This iscarried out on polesto the locality inwhich it is to be used.Here it is stepped down to 110… … Figure 223. Wiring Diagram of a HouseCircuit.
