Gut —> T~ime. - 30 - ourve in Fig. lla. The curve represents a cosine functionbecause the hunting of an electrical machine is a hamonicmotion. By a continuation of the motion it is apparent thatits result represents the voltage induced in each rotor barof a generator with an amortisseur for a… … The value of 0° may he calculated from the vectordiagram of the machine as follows. The assumption has beenmade that the machine is carrying full load current at unitypower factor. The vector F will then he displaced as shownby angle 0Q which, when the machine is released by the loadbeing thrown…
