the influence of the jet.A motor constructed on this plan is, however, impracticable. 40. Case III. Jet Striking a Moving Curved Vane Tax-GENTIALLY. Fig. 22 represents a case in which the jet, with anabsolute velocity v, impinges tangentially upon a vane which moves inthe same direction with the… … moving and ini})inging with the al)sohitevelocity r—». Hence, for the dynamicpressure in the direction of the jet, wemay use Etjuation 2G, substituting v -ufor r; so that, P = (l-cos/?)TT^^^ (36) 9 While the dynamic pressure may be ex-erted with different -intensities upondifferent parts of the…
