Hydraulic engineering; a practical treatise on the principles of water pressure and flow and their application to the development of water power, including the calculation, design and construction of water wheels, turbines, and other details of hydraulic power plants (1909)
American School (Chicago, Ill.), Black, Adolph, Turneaure, Frederick Eugene, 1866- · Chicago American School of Correspondence · leaf 148
Fig. 43. Runner of 8,000-H.P. Doble Water-Wheel in DeSabla Power Plant.Velocity of jet, 20,000 ft. per minute. … Fig. 44. The Cascade (Leffel) Impulse Wheel.Three-nozzle system. 64 WATER-POWER DEVELOPMENT the samo time deflecting it backwards, ()})posite the direction ofmotion, as in Fig. 41, Figs. 42 and 43 show the usual method of attaching the bucketsto the wheel; it is clear that in these designs one or…
