Mechanical equipment of buildings; a reference book for engineers and architects (1916)

Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 211

An illustration from Mechanical equipment of buildings; a reference book for engineers and architects, 1916, leaf 211 — lable use motor-driven vacuumptunp, about M H.P. Use 1 inch air mains in basement and gate valve on each air riser. Steam usedvaries from 1 to 5% of total condensation. All radiator connections as shown. Air Line Systems with Gravity Circulation. The Paul Air Line System can be appUed toeither one… … Fig. 17. Belted Co.mpre.ssor.

Building · Heating · Ventilation
