Fig. 10^. Risdon Register-Gate Turbine.Outside Register Pattern. Jiisdon-Alcott Turiiue Co. 146 ^VATER-PO^YER DEVELOPMENT momentary opening of the valves. They may be placed singly or ina batten\ Fig. 117 shows two types of safety air-valves designed to open … Fig. 103. Alcott High-Duty Turbine.Inside Register Pattern. lihdon-Alcott Tui-hine Co. automatically in case the pipe-line should be emptied suddenly, thuspermitting the air to rush in, and preventing possible collapse of thepipe due to the formation of a vacuum. Fig. lis illustrates a compensator…
