Fig. 139. Filler Gate.With frame for bolting to a timberhead-gate. Allows passage of sufficientwater to equalize pressure, so that head-gate need not be lifted imder total pres-sure.Dayton Globe Iron Works Co., Dayton. O. … Fig. 130. Head-Gate and Hoist. Square, east-iron gate.Dayton Globe Iron Works Co., Dayton, 0. of removable sections 3 or 4 feet wide is frefjuently used, instead of acontinuous rack. 185. Head=Gates. The purpose of the head-gate (see Figs. 124to 136) is to control or shut off the water from a…
