Hydraulic motors, with related subjects, including centrifugal pumps, pipes, and open channels, designed as a text-book for engineering schools (1905)
Church, Irving Porter, 1851-1931 · New York : J. Wiley & Sons; [etc, ] · leaf 117
olongation, CC, or cylin-drical gate, movable vertically and having rounded edges onits lower periphery. This lower edge is also slotted to receivethe curved stationary guides which are shown (in the hori-zontal section) at G and which are rigidly attached to thefixed plate c. . c. This plate is… … Fig. 47.
Hydraulic machinery
