Hydraulic motors, with related subjects, including centrifugal pumps, pipes, and open channels, designed as a text-book for engineering schools (1905)
Church, Irving Porter, 1851-1931 · New York : J. Wiley & Sons; [etc, ] · leaf 204
Fig. 83. SNOWSWATER-WHEEL GOVERNOR … Fig. 84. l65 166 HYDRAULIC MOTORS. § 104. horizontal shafts at G turn continuously, being in gear withthe turbine, but the third one, B, turns only, and in the properdirection, when the speed of the turbine changes slightly fromthe normal, and moves the turbine gate by means of wthebevel-gear at B.…
Hydraulic machinery
