Hydraulic motors, with related subjects, including centrifugal pumps, pipes, and open channels, designed as a text-book for engineering schools (1905)
Church, Irving Porter, 1851-1931 · New York : J. Wiley & Sons; [etc, ] · leaf 39
equal to h, the fall or vertical head fromhead-water, H, to tail-water, T. If the various dimensions of the wheel, the quantity ofwater used per second (Q), the velocity of rotation of thewheel, and the resistance Rr (lbs.) tangent to the rim of thegear-wheel A, are properly adjusted to each other,… … Fig. 6a. JfcV ft.-lbs. per sec.) on the resistance (i/ being the velocityof the rim of wheel A). For example, R may be the resistingpressure of the teeth of a pinion keyed on another shaft operat-ing the machinery of a mill. The buckets should be of suchshape and size, in connection with the proper…
