Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 83

An illustration from Mechanical movements, powers and devices, 1911, leaf 83 — 243. GRIDIRON SLIDE VALVE, for large port area with small motion of thevalve. … 244. ROTARY VALVES.—The valves K and L arethree-winged cylinders, andare nearly balanced by thedouble inlet ports of thevalve chamber. STEAM POWER. 73
