g mechanism are interlocked to prevent both being thrown in at the sametime. The table shown in the plate is 8 ft. long by 36 wide, and is adjustableto and from the cutter-head to regulate the amount of feed. Fast and loose pul-leys on countershaft are 24 diameter for 4 belt, and should make 260… … ROTARY PI.ANER FOR ARMOR PLATES. The cutter-head having 75 tools, arranged in circle 50 diameter, will planework 26 ft. long, carried upon two tables, each 8 ft. long by 7 ft. 6 wide.These tables are adjustable to and from the cutter-head by power to regulatedepth of cut ; the head is provided with…
