Burn, Robert Scott · London : Ingram, Cooke, and Co. · leaf 108
fi°r. 66, o the shadow of the tower on the slopes of the roof, L being the luminarysplace, F its foot, and the shadow being thrown rather towards the spectator, … fig. 67. the rays being at a small angle with the picture. From F draw a b acrossthe ground-plane, from the front corner of the base of the tower, throughthe side of the church ; on which carry up b c parallel with the angle of thetower to the roof of the side-aisle at c. From the point d on the…
Drawing · Wood-engraving
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
