fig. 83. fig. 84. draw h m ; draw fe, and from e and m draw lines a and parallel to g nor be ; from n n draw lines meeting in the point o, and put in the line h o :the drawing is complete. From an inspection of the figs. 85 and 86, the … fig. 85. fig. 86. pupil will be able to draw in the representation as given. Fig. 87 givesthe isometrical representation of two blocks of stone. In fig. 88 a repre-sents a block laid across two blocks placed in
