Burn, Robert Scott · London : Ingram, Cooke, and Co. · leaf 133
lace, e the window; c d is the dining-room, a the fireplace, and e thewindow. F is a study or small sitting-room, P a closet, H the backentrance, L the staircase-lobby, K the kitchen, k the fireplace. Fig.127 shews the method of representing agricultural enclosures, or walls ofgardens, &c.; a… … PERSPECTIVE DRAWING. 125 may be measured, but also for the measurement of the enclosing erections.
Drawing · Wood-engraving
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
