Burn, Robert Scott · London : Ingram, Cooke, and Co. · leaf 87
fig. 46. of an up-MU view (fig. 46), in which the plane of the surface rises upwardsfrom the spectator; or of a down-hill (fig. 47) view, in which the surfaceinclines downward from him; or of sloping objects, such as the roofs of … fig. 47. many houses, which incline side-ways from him, the vanishing-points willobviously be either above or below the horizon, and the degree of theirdeviation from it will depend on the degree of the inclination. Thisbrings us to the consideration of inclined plmies, the vanishing-points ofwhich…
Drawing · Wood-engraving
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
