Burn, Robert Scott · London : Ingram, Cooke, and Co. · leaf 94
e by the aid of vanishing-points, two PERSPECTIVE DRAWING. 85 examples will now be given, and the manner of treating them explained;the one being an interior view of a room, with its doors partially open, atvarious degrees of obliquity ; the other an exterior view of a house with aprojecting… … and let the upper part ABCE be the boundary of the proposed view.Draw the base-line AB of the picture in plan, with its ends produced,intersecting the plan at such a distance that the extremities A B of the 86 ILLUSTRATED LONDON DRAWING-BOOK. part beyond it, which is all that is to be included in…
Drawing · Wood-engraving
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
