Illustrations of the theory and practice of ventilation : with remarks on warming, exclusive lighting, and the communication of sound (1844)

Reid, D. B. (David Boswell), 1805-1863 · London : Longman, Brown, Green, & Longmans · leaf 308

An illustration from Illustrations of the theory and practice of ventilation : with remarks on warming, exclusive lighting, and the communication of sound, 1844, leaf 308
cloth is changed daily. 650. Fig. 221 gives a connected view of the different pointsreferred to in the preceding paragraphs ; a the vitiated air fromthe drain in Old Palace Yard, controlled by the undergroundventiduct, and conveyed directly to the shaft; b the fresh airentrance when the air is… … 284 VENTILATION OF THE HOUSE OF COMMONS. ing the air ; d e the hot air chamber communicating with e, thelower air chamber, which receives warm, cold, or mixed air, ac-cording to the temperature required ; // deflectors for diffusingthe air in the equalizing chamber g g; bb the supply for…

Ventilation · Heating · Lighting · Architectural acoustics
