An improved and enlarged edition of Biddle's young carpenter's assistant : being a complete system of architecture for carpenters, joiners, and workmen in general, adapted to the style of building in the United States ; revised and corrected, with several additional articles, and forty-eight new designs, chiefly of full size, working drawings of modern finish, in detail ; particularly adapted for country use (1833)

Biddle, Owen, Haviland, John, 1792-1852 · Philadelphia : M'Carty & Davis, 171 Market Street · leaf 71

An illustration from An improved and enlarged edition of Biddle's young carpenter's assistant : being a complete system of architecture for carpenters, joiners, and workmen in general, adapted to the style of building in the United States ; revised and corrected, with several additional articles, and forty-eight new designs, chiefly of full size, working drawings of modern finish, in detail ; particularly adapted for country use, 1833, leaf 71
S C.I I. K FLATE ^4. … jr. linnijj /(. THE YOUNG CARPENTERS ASSISTANT. 21 PLATE 23. In this Plate is given a flat pediment frontispiece. The observations made on thepreceding example, with respect to general proportions, Mill apply to this. After tiie Student lias fixed on the size of his door, he will draw the arch,…

Architecture · Architectural drawing

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
