Industrial drawing and geometry; an introduction to various branches of technical drawing (1911)
Spooner, Henry John, 1856- · London, New York [etc.] Longmans, Green, and co. · leaf 122
ote.—You should carefully examine a wire model of this solid; beginners often blunder by assuming that the height is eqnal to the length of the edges, 186. A Cylinder with its Base on the H.P. is cut by a Plane passing through the Top Left-hand Corner of its Elevation, and makingan Angle of 60 with… … Fig. 306.—Hexagonal section.
Mechanical drawing · Geometrical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
