Pigs. 465,466.—Elevation and sectional elevation of a straight arm belt-pulley. Pig. 467.- … PiGS. 469, 470.—Locomotive crank, WordEells pattern. Section of segmental arm. Pig. 468.—Section of elliptical arm. this to think out which lines will be seen-after the body has been cut along the sectionline. By now you should be able to do thisvery well. 248. Couplings. — Whenever a line…
