Fig. 71. CIRCUIT-BREAKING RELAY The circuit-breaking relay is an electro-magnet with a single winding. It opens andcloses the circuit leading to the lamps, heater unit, horn, and ignition apparatus at contact E. When a ground or short circuit gets on one of the wires, it causes an excessive flow…
