The practical testing of dynamos and motors (1905)
Smith, Charles Frederick, 1873- · Manchester Scientific Pub. Co · leaf 125
stic makes withthe horizontal. In an actual machine it is not possibleto obtain a characteristic which is a straight line. Lon^ and Short Shunts.—There are two methods ofconnecting the series and shunt windings of a compoundd^Tiamo. A long shunt dynamo has the shunt windings con-nected in parallel…
Dynamos · Electric motors
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
