Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 249
VVtrnin Diagram Coil DCR Fig. 12, 246 INFORMATION Distributor Plate Soiled. Remedy—Take out distributor arm and clean all the contacts of the distributorplate with gasoline. Irregular Firing. Remedy—This can be caused only by the improper Avorking of the contactbreaker. Remove the cover by pressing… … s g;a u MAGNETOS 247 See that the make-and-break mechanism is well in place by tightening screw andalso that both platinum contacts are rigid. If the contact lever is jammed, cleanthe lever axle as well as the lever by lightly rubbing with emery paper or clothand slightly oil the axle. Cables. (a)…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
