Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)

Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 27

An illustration from Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car, 1920, leaf 27 — 110 YOt-TS THE DROP IN PRESSURE BETWEENGENERATOR AND MOTOR IS DUE TOTHE RESISTANCE OE RHEOSTATBEltKG CUT If/. —___ … PRES Stiff £(//$)GAUGE

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
