Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 291
FIG. 33 Figure 33. lation. This shows the circuits of a generator employing third brush regu- … ELECTRIC TESTING 289 Figure 34. This shows the lighting wires tapped off the two lines from thegenerator to the storage battery. There is a corroded joint, or connection, at A.When the generator is running and supplying current to the system, the lightswould be exceptionally bright; and when the…
Automobiles
