For an explosion occupying ten times as long, i.e. T^^•sec, the indicator would still be lagging a long way behind. For a?i^ sec. explosion the actual maximum pressure would be very fairlyrepresented, but not the shape of the explosion wave. In fact foruseful readings the instrument should not be… … Line showing actualrise of Pressure . Line showing record madeby undamped Indicator. -yen Time in Seconds Fig. 48.—Diagram illustrating the way in which an undamped Indicatorwould follow a rapid explosion. Period of Indicator, a£s sec. to a gas engine is a statement of the way in which the…
