The internal combustion engine; a text-book for the use of students and engineers (1915)
Wimperis, Harry Egerton, 1876- · New York, D. Van Nostrand company · leaf 267
to be introducedbetween the engine and the road wheels. This brings us to the consideration of the mechanism bywhich the power of a petrol engine is transmitted to the roadwheels of a car. This is shown diagrammatically in Fig. 75,whilst in Fig. 76 is seen a Talbot Chassis showing how… … O H f-t© .g i—i o iX ■ iH w O 03 Q d M from the front of the car to the back and its continuation iscalled the propeller shaft, owing to its being similarly placedto the propeller shaft of a screw steamship and actually being chap, viii] OIL AND PETROL ENGINES 245 the propeller shaft when used in a…Internal combustion engines
