Right <ide of new 18-hp. Phoenix engine. Overhead camshaft has four bearings and is driven by helical gears. Magneto ignition is used. Note recesses for nuts on inverted holding-down studs Left side of Phoenix engine, showing water bolted to facing on block casting of erankcacylinders. Cored… … Cantilevei springs oh neu: Phoenix chassis arelocated inside the frame. Trunnion bearing atcenter has oil-less bushing bearing upon the tubu-lar cross member of the frame. Ends of springshave sliding contact on axle and frame bracket.Side member of frame is cut off short to giveclearance to brake…
