The internal combustion engine; a text-book for the use of students and engineers (1915)
Wimperis, Harry Egerton, 1876- · New York, D. Van Nostrand company · leaf 272
rolflows in. Theweight of the floatis so adjusted thatthe petrol-level iskept at just theright height. It isthe custom to havethe petrol standingjust below the topof the jet, but it Fig. 79.—Jet Carburettor and Float Chamber. works even ifA. Petrol inlet. B. Needle valve. G. Float _. , , which… … 250 THE INTERNAL COMBUSTION ENGINE [chap, viii this is seen in instances in which the float chamber is suckedquite dry during the running of the engine when the petrolinlet pipe A has got choked up in some way. The principleof the working of the jet will be gone into later. An effici-ent type of a…
Internal combustion engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
