The inventor's universal educator. An educational cyclopaedia and guide for inventors, patentees, manufacturers, mechanics, and all others connected directly or indirectly with patents (1919)
sentially of themain planes 1, the fan-shaped tail 2, propellers 3, car 4, in which the passengers and engine were to be located; theplanes were to be light frames covered with silk; a lateral direction rudder 5 was to be provided, and the tail 3was to be hinged on a horizontal axis to act as an… … [ 150 ] THE WRIGHT BIPLANE. The frame is constructed of ash and spruce; the supporting planes 1-1 are identical in construction, and aremade of canvas stretched over the ribs; the machine is propelled by two rear propell rs 3-3 chain and sprocketdriven from the motor 2; a double vertical rudder 4-4…
