inary running.The voltage varied directly with thespeed giving almost a straight line when the curve was drawn.The usual minimum battery charging voltage coming at about750 revolutions per minute of the generator and increasingalmost one volt for each additional 100 revolutions per minute.This is… … JO «0 5L 3 Q:2 s ■o 5 *5 5 r 8 B . ^ fiff •■lip <T i« XT / / / i 1 I — -.* 1, • i _s s 3 d -9- The series coil has very little effect in this case as willbe shown later,since the only current passing through it is thecurrent for the shunt coil. The next test was a no load one with the series…
