Investigation of inverse time limit overload relays (1915)
Deiss, William Charles · leaf 56
e field, up to a certain point, between three and four timesfull load current, the induced current in the armature will in-crease in proportion to the current in the field coils. Thetorque and speed are increased accordingly• After this latterpoint, the magnetic circuit becomes saturated, due to…
Short circuits · Electric apparatus and appliances · Electric conduits · Theses
Internet Archive · University of Illinois Urbana-Champaign · Public Domain Mark 1.0. Free to use for anything.
