Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 202
shell of the back rail to the web. The respective details illustratedand Web. F are the warp k, back rest l, auxiliary easing bar m, easing harness c9 c10 etc., regular harness a1 etc., doup standards b9 etc., reed q (where each group of four warp threads are shown GAUZE AND LENO JACQUARDS. 197… … O (D <U U y l. 3 7 f|f|f|lp|ftf||f -TiniWiihM-T^ Fig. 191. over 2 picks, and ordinary plain weave. In the top left hand corner,where the gauze is being formed, the doup standards b together I98 JACQUARD MECHANISM AND HARNESS MOUNTING. with the doups and crossing threads are shown on the right…
Textile machinery
