Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 218
led to rise, and thecard cylinder to strike, only on the figuring shots. Briefly, the operations of weaving with one shot of ground,alternately with one shot of figure, is as follows:— First pick :—Gauze ground. Leave down all the harness g withthreads b, pull tug reed h slightly to the left so… … Fig. 205 214 JACQUARD MECHANISM AND HARNESS MOUNTING. moves to the left of each respective thread a in the same split; liftthe easing rod I and the gauze reed J with the crossing threads a,which therefore rise on the right side of the regular threads b ;insert the ground weft c, depress the easing…
Textile machinery
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
