th the shuttle box mechanism. Fig. 212 is a front elevation of the suspended gauze reed. Fig. 213 is a side elevation of the controlling details as viewedfrom the left hand side of a right hand loom. The position of the parts in Figs. 212 and 213 represents thereed in its highest position. Fig. 214… … Fig. 211, Fig. 208. Fig. 209. Fig. 210. 2l6 JACQUARD MECHANISM AND HARNESS MOUNTING. inserted. The letters indicate parts that have already been detailedand similar numerals in the three diagrams refer to correspondingparts. The gauze reed J is suspended by leather straps and buckles iand i1 from…
