173. tinuously from a supply of the molten metal. According to theinvention, the molten metal flows from a tank, 1, into an inclinedrotating cylindrical chamber, C, which may be heated electricallyor otherwise. It is drawn from the lower end, either by hand ormechanically, in the form of a tube, T,… … Fig. 174. 307725).—The ladle employed consists of two jaws, 1 and 2,pivoted together and capable of opening 180°. These jaws aresupported on a pipe, 3, through which passes a shaft, 4, and both . MACHINERY FOR THE WORKING OF GLASS. 255 are provided with handles, 5 and 6. At the other end, section…
