128 JUTE AND LINEN WE A VING CHAP. 2. Throw or stroke of wyper (say 3J ins.). 3. Dwell of wyper (one-third of a pick, or 120° of the crank circle). 4. Diameter of treadle bowl or anti - friction roller (say 3 ins.). … H FIG. 60. From a point A on a vertical line set off B (the distance from the centre of the wyper shaft to the centre of the treadle bowl when the treadle is level — viz. 6 ins.). Above and below B set off at C and D half the throw of the 31 wyper — viz. - - = 1| ins. With A as centre, and AC, AD…
