Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 128
edles in the dial and those in the cylinder, work in thecenter of space between the needles of the opposite plate, and as thefabric on the machine is varied in thickness, either the dial or cylinderdrivers are made adjustable, especially in large machines. Fig. 40represents a cylinder wath… … Fig. 45. Dial Cap. the stitch cam, and F, the uard cam, and their locations. Fig. 40shows each cam in detail. On plain machines, cams F* and F^ areoften made in one piece corresponding to cam B in the cam ring;but in automatic machines, the tuck stitch which widens the fabricis made by moving the…
Knitting machines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
