intended for operatinghoists, etc. Fig. 1572 shows one of the above motors withadjustable resistance in the secondary, the handle h shownin the figure being used to operate the sliding collar c. It alsosho\ys the arrangement of the parts of a motor with station-ary field and revolving armature.… … Fig. 1573. whichever way is best suited to the conditions under whichthe motor is to work. If, for example, the field were to beconnected to high-potential mains, it would probably have 2724 THEORY OF ALTERNATING its coils connected up Y. Fig. 1573 shows the arrangementof coils for a simple…
