Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 130
p plate ring, towhich are secured the cap plate straps F*, which move the cams, towhich they are connected, in and out for the purpose described above. 116 KNITTING 103 In the ring F is fixed a stud F to which is fastened the strap or con-necting rod M (Fig. 39), which transmits motion from the…
Knitting machines
