Fig. 86. length on similar line in Fig. 83. For the pattern take the dis-tance of 1 10 and place it as shown by 1 10 in Fig. 85. Using 1as center, and 1 2, Fig. 83, as radius, describe the arc 2 in Fig. 85;intersect it by an are struck from 10 as center and 10 2, Fig. 84,as radius. Then using 10 9…
