Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 268
m outside the plate has feather-splined on it a gear n^, whichis kept on by the screw n^. The gear meshes into the rach n^, whichis connected to the slide block n*, fitted into the guideway n^ of theplate N. When the rack is moved up it turns the gear on the stem ofthe switch and sets it in… … finished, to lead down all the needles previously lifted, and then to beraised in circular knitting. The rack has a cam face at one side, with which co-operates alocking device w*, which serves to hold the rack in position as left byits actuating device. When the narrowing in the heel and toe…
Knitting machines
