Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 326

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 326
oes higher until it reaches the top of the bobbin. This 291 250 COTTON SPIXXIXG is accomplished in the following way: The worm, W-, instead ofengaging a rack as on the warp builder, is in gear with a worm gear,Y^, the hub of which is made as a drum upon which the builder chain,T^, is wound. The… … Fig. 213. Filling Builder. turned, it is gradually unwound and the traverse is allowed to gohigher on the bobbin. The builder is wound back x^ith a key, thesame as the warp builder. The filling cam, O^, is made with tliree lobes, so each revolutionof the cam shaft causes the ring rail to make three…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
